Mailbox with E-Mail Notification and Solar Panel

The following blog post was sent to us by our customer Helmut Schmidt. This is a mailbox that sends notifications via email when mail has been deposited. The power supply was realized with small solar panels and rechargeable batteries. Have fun reading and tinkering with it:

The mailbox was built together with a work group of a retirement and nursing home. The idea was to equip the mailbox with an e-mail notification. As soon as someone drops in a wish list, an e-mail is sent to a group of volunteers, the Green Ladies. After all, no one is going to check the mailboxes every day. The result was a mailbox with a solar module and an ESP8266 D1 mini. The program uses Deep Sleep until a wish list is posted or the door of the mailbox is opened.


Required hardware


D1 Mini Nodemcu with ESP8266-12F WLAN module


LM2596S DC-DC Power Adapter Step Down Module

1 or 2, depending on the ambient brightness

Mini SolarPanel Debo Solar 0.5W 5V


Ultra-fast avalanche sintered glass diode BYV 27/200


Li-ion battery, 18650, 3.7 V, 2600 mAh, incl. MicroUSB charging socket


Alternatively Li-Ion battery, 18650, 3.7 V


Alternatively NiMH batteries


Battery holder


680 KOHM resistors for voltage divider


10 KOHM resistors for voltage divider




1 μF capacitors (tantalum)


common diodes

1 counter


Download Additional Board Manager Ulr
File> Preferences:

Install the nine packages with the board dress
Tools> Board> Board manager:
ESP8266 by ESP8266 Community

After installation, you will find all ESP8266 boards. Select Lolin (WEMOS) D1 Mini & R2.

Under File> Examples of D1 Mini> ESP8266 If the LowpowerDemo is located with 10 tests for Modem Sleep, Light Sleep and Deep Sleep.

This blog post has already described in detail how to send G-Mails via ESP8266:

In the blog post Sending G-Mails via ESP8266 it has already been described in detail how to send G-Mails via ESP8266. This still needs its own library of getting charged. Then you can Sketch> Add File> Open The just downloaded .zip-Choose a file. over File> Examples from own libraries> ESP8266SMTP Find the G-Mail program.

It is highly recommended that you create your own email account to send emails to your main personal email address. Do not use your main personal email address to avoid accidentally blocking or temporarily disabling your account. For experiments, it is recommended to use a account to send the emails. The recipient email can be your personal email.

All details for setting up a account and an e-mail address can be found at the following link.

Connection between solar module, battery and ESP8266

The specifications were the most inexpensive application with one or two solar panels. Normal Ni-MH batteries have the disadvantage of a relatively high self-discharge, monthly around 15-25%. Meanwhile there are better Ni-MH batteries with a self-discharge of only 15% loss within one year, but then similar in price to Li-Ion. Two solar panels deliver over 5 V and mostly over 10 V at usual room brightness. Under load, the voltage usually breaks below the maximum charging voltage. Due to the protection function in the Li-Ion battery itself (or with LM2596S DC-DC power supply adapter) voltages of 7 V are no problem. However, Ni-MH batteries should be charged to a maximum of 1.4 V. A 18650, 3.7 V, 2600 mAh, incl. MicroUSB charging socket was also selected as the Li-Ion battery. Thus, the protection circuit is already integrated in the battery. The first outdoor tests showed sufficient charging by the solar panels, both with NiMH - and LiIon - batteries. At room brightness, Ni-MH had the lead. Obviously, at low charging currents, the protection circuit consumes more current than is stored in the batteries. One possibility would be to use a Li-Ion battery without built-in protection circuitry just by limiting the current by switching with the ESP8266.

To prevent overcharging, the deep sleep is briefly interrupted by the RTC timer for a voltage measurement. If, on hot days, the voltage is close to the maximum charge voltage, the Wifi is activated and the voltage is brought back to the norm. The measurement is done with analogRead(pin_voltage) at GPIO A0. The Wemos D1 mini already has a voltage divider of 220 kOhm / 100 kOhm built in, with an internal resistance of 320 kOhm. If another resistor of 680 kOhm is added between A0 and Vin, the voltage range is extended from 1 V to (680 + 320)/320 = 3.1 * 3V = 9.3 V. The measured voltage must therefore be identical with the measured voltage. The measured voltage must therefore be multiplied by the factor 9.3.


If the voltage drops close to the end-of-discharge voltage, the first thing to do is charge the battery for some time. For Li-Ion batteries the final discharge voltage is 3.5 V, for Ni-MH batteries 1.1 V. To safely exclude reverse current from the battery to the solar panel, the solar panel and converter are connected via a BYV 27/200 diode. The actual task of the ESP8266 is done by WAKEUP. It is recommended to load the LowPowerDemo on the ESP8266 beforehand to try out all possibilities. It is best to operate the ESP8266 with an external voltage source and to display the current consumption with a measuring device. With runTest6 in Forced Light Sleep the minimum current consumption is 0.9 mA, in Deep Sleep only 0.15 mA. However, Deep Sleep only allows a single external signal for wakeup. The RTC timer also runs in Deep Sleep. As soon as the time of ESP.deepSleep(microseconds) has expired, LOW is applied to D0/GPIO16. So if D0 and RST are connected, the EPS8266 is reset. So that further signals can be evaluated, it needs still voltage dividers from in each case a resistor and a capacitor (s. circuit).

circuit diagram

The symbols of the LEDs behind the BYV 27/200 diode represent the solar modules. The switch (shown as dip switch module on the photos) disconnects or opens the connection to the battery.

As soon as a letter is inserted, LOW is applied via microswitch D5. When the letterbox is opened, LOW is at D7. Via the capacitor the reset is executed for a short time. The ESP8266 starts up and registers the inputs of D5 and D7. The time constant must be as short as possible so that the spike executes the reset safely, but the input at D5 and D7 is still LOW. The diode between RST and D0 allows to program the ESP8266 as well.

D1 mini wired

It is also important to monitor the WiFi status. Should a connection to the network fail, the attempt to connect is aborted after wifiTimeout = 60 seconds. The next attempt is made by the timer after about 71 min. If there is still no connection to the network after a longer time, the voltage will drop below the minimum voltage and, as described above, the battery will first be recharged. The triggering event is stored in the EEPROM.

Calculation of the power consumption

Without solar panels, the consumption in Deep Sleep is 0.15 mA . Assuming one email per day, the consumption is about 60 mA for about 30 seconds. Per day this makes 0.15 mA * 24 h + 60 mA * 1/60 / 2 h = 4.1 mAh. With a Li-Ion battery with 2600 mAh, the D1 mini could thus be operated 2600 * 70% / 4.1 h = 440 days without interruption. Even at room brightness, the two solar modules supply about 0.5 mA, which makes about 0.5 mA * 12 h = 6 mAh. This should cover the power consumption completely. Outdoors, the performance of the solar modules would be even better. For security reasons, the battery charge status is displayed with every e-mail. When sending, peaks of up to 200 mA occur. After sending an email (with 3 NiMH batteries) the same voltage was measured after 3 hours as before the email. Measurements for charge and discharge voltage by an ammeter should be taken with caution. Especially at the reversal point (about U = 0 and I = 0) with an electronic meter, the reading depends on its internal resistance. So if unusual values occur, the remedy is to set the measuring range to 10 A, with 10 mA steps.


All batteries have advantages and disadvantages. A LiFePO4 battery has a voltage of 3.3 V and would therefore be suitable, but also requires a safe protection circuit, as it must not be charged above 3.65 V. NiMH batteries have the disadvantage of higher self-discharge. LSD NiMH (low self-discharge) are best. The use of LiIon batteries depends on the ambient brightness. No warranty is given for Li-Ion batteries without protection circuit. Alternatively, a NodeMCU-32S was also tried. The power consumption was 9.8 mA during "deep sleep". You can say the NodeMCU-32S was more in half sleep than deep sleep. The NodeMCU-32S does not disable the USB port during deep sleep. Current consumption below 20 µA is possible with the DFRobot FireBeetle ESP32 IoT and DFRobot FireBeetle ESP-12F (ESP8266) IoT.


The long-term testing of the mailbox with e-mail notification and solar panel is still pending. The big problem is to realize the permanent power supply. Solar panels do not always provide enough voltage and the stored current in the batteries may not be sufficient. A change from the ESP32 to the ESP8266 helped a bit because of the lower power consumption. But it was also important to show how to use three inputs despite Deep Sleep.


Suggesting of an open source weather sensor:

ESP8266WIFI library documentation:

Enclosed the entire program with notes or here as a download:

Remember to enter your wifi and email account details (from line 36 and 90)
 // MINI_SOLARPANEL 5V and Battery Connect via ultrafast avalanche sintered glass diode BYV 27/200 //
 // author:
 // dr. Helmut Schmidt <>
 // liion_akku
 // const int load voltage_max = 5500; // The ideal charging voltage for lithium-ion batteries is around 4.2 volts. Lion battery protected from overvoltage
 // const int load voltage_min = 3500; // discharge voltage
 // for NiMH_Akkus
 byte N_Akkus = 3;
 contam int Charging tension_max = N_Akkus * 1400;  // Load voltage max. 1.4 V for NiMH_AKKU
 contam int Charging tension_min = N_Akkus * 1100;  // discharge voltage = 3.3 V minimum under load
 int tension;
 contam int pin_ voltage = A0;
 byte flag_post = false, flag_lustration = false,
 uint16_t Outstanding_email = 0;
 uint16_t e-mail = 0;
 uint32_t time-out = 60E3;  // 60 Second Timeout on the WiFi Connection
 // for w a k e u p //
 #define push button_leung 13 // D7 / GPIO13
 #define taster_post 14// D5 / GPIO14
 #define wake_up_pin 0 // wake_up_timer is connected to D0 / GPIO16 in ESP8266 >> D0 causes a reset
 // for WiFi //
 // Enter Your Wifi Configuration Below
 contam Char * Ap_sid = "WiFi Network Name";                // WiFi Network Name
 contam Char * Ap_pass = "WiFi Network Password";            // WiFi Network Password
 void set up() {
   pinmode(Wake_up_pin, INPUT_PULLUP);
   IF (digitalRead(TASTON_LECTION) == Low) flag_lustration = true;    // pushed button
   IF (digitalRead(TASTON_POST) == Low) flag_post = true;
 // s p a n n u n g s k o n t r o l e
 // Indoor resistance in Wemos D1 Mini is 320 Kohm with a voltage divider of 680kohm / 320 KOHM should
 // Material is converting factor 3.1 * 3 = 9.3. Voltage in MVolt.
   tension = analogead(pin_ voltage) * 9.3;
 //////////////////////e////// //////www.hrägnänd
 // voltage = 4000;
   // data from the EEPROM
   Outstanding_email = EEPROM.reading(0); e-mail = EEPROM.reading(4);
   IF (flag_post == false && flag_lustration == false && tension < Charging tension_max && Outstanding_email == 0)  ESP.deepsleep(0xffffffff);   // continue sleeping
 // Do not activate WiFi at post and undervoltage
   IF (tension < Charging tension_min) {
     IF (flag_post == true) {                // Deepsleep o H N E WiFi
       EEPROM.writing(0, Outstanding_email);  EEPROM.commit();
       Serial.Begin(115200);  Serial.Println("Outstanding_email" + String (Outstanding_email)); // only for testing
     ESP.deepsleep(0xffffffff);               // Convert
   Serial.Println("Voltage =" + String(tension) + "Mvolt");
   Serial.Println("Start Up");
   Wifi.persistent(false);    // Do not Store The Connection Each Time To Save Wear On the Flash
   Wifi.SetOutputPower(10);   // Reduce RF Output Power, Increase IF It Won't Connect
   Wifi.Begin(Ap_sid, Ap_pass);
   Serial.print(F("Connecting to WiFi"));
   int wifitime = millis() + time-out;          // or 60 sec
   While (Wifi.status() != Wl_connected && wifitime > millis()) {
     Serial.print(".") ;
     delay (1000);
   IF (Wifi.status() == Wl_connected) {
    .setforgmail();                        // simply sets port to 465 and setServer ("");
     IF (flag_post == true || Outstanding_email > 0) {
       e-mail++;  EEPROM.writing(4, e-mail); Outstanding_email = 0; EEPROM.writing(0, Outstanding_email);
       SMTP.Broadcast("", String(tension) + "Mvolt \ R" + String(e-mail) + "A Wishlist has entered the mailbox on the station 2");
     Else IF (flag_lustration == true ) {
       SMTP.Broadcast("", String(tension) + "MVolt \ R mailbox leered on the station 2");
       Outstanding_email = 0; EEPROM.writing(0, Outstanding_email); EEPROM.writing(4, 0);
     Else IF (tension > Charging tension_max) {
       SMTP.Broadcast("", "Overvoltage voltage =" + String(tension) + "mvolt email =" + String(e-mail) + "Outstanding email =" + String(Outstanding_email));      // comment on possibly
       ESP.deepsleep(0x10000000) ;      /// all 10 sec for degradation of overvoltage
 /////// Only for testing the timer
        Else IF (true) {
           SMTP.Broadcast("", "email =" + String(e-mail) + "Outstanding email =" + String(Outstanding_email) +  "Voltage =" + String(tension) + "Mvolt");      // comment on possibly
 /////// test end
   ESP.deepsleep(0xffffffff); // microseconds number of microseconds to sleep. The maximum value is 4294967295US or ~ 71 minutes.
   // It wants Never get here!
 void loop() {   // It wants Never get here!
 ///////// For the right use, comment all serial print commands ////////////
