Flexibles RGB LED Panel WS2812B - Produktvorstellung

This video showcases the 16x16 LED RGB matrix. It covers all the technical details and provides a wiring example. In the end you get two different code examples to learn how to use the panel.



You can get the panel here:

RGB LED Panel WS2812B


Wiring diagram:


Code example 1:


// Adafruit_NeoMatrix example for single NeoPixel Shield.
// Scrolls 'Howdy' across the matrix in a portrait (vertical) orientation.

#include <Adafruit_GFX.h>
#include <Adafruit_NeoMatrix.h>
#include <Adafruit_NeoPixel.h>
#ifndef PSTR
 #define PSTR // Make Arduino Due happy
#endif

#define PIN 16

// MATRIX DECLARATION:
// Parameter 1 = width of NeoPixel matrix
// Parameter 2 = height of matrix
// Parameter 3 = pin number (most are valid)
// Parameter 4 = matrix layout flags, add together as needed:
//   NEO_MATRIX_TOP, NEO_MATRIX_BOTTOM, NEO_MATRIX_LEFT, NEO_MATRIX_RIGHT:
//     Position of the FIRST LED in the matrix; pick two, e.g.
//     NEO_MATRIX_TOP + NEO_MATRIX_LEFT for the top-left corner.
//   NEO_MATRIX_ROWS, NEO_MATRIX_COLUMNS: LEDs are arranged in horizontal
//     rows or in vertical columns, respectively; pick one or the other.
//   NEO_MATRIX_PROGRESSIVE, NEO_MATRIX_ZIGZAG: all rows/columns proceed
//     in the same order, or alternate lines reverse direction; pick one.
//   See example below for these values in action.
// Parameter 5 = pixel type flags, add together as needed:
//   NEO_KHZ800  800 KHz bitstream (most NeoPixel products w/WS2812 LEDs)
//   NEO_KHZ400  400 KHz (classic 'v1' (not v2) FLORA pixels, WS2811 drivers)
//   NEO_GRB     Pixels are wired for GRB bitstream (most NeoPixel products)
//   NEO_GRBW    Pixels are wired for GRBW bitstream (RGB+W NeoPixel products)
//   NEO_RGB     Pixels are wired for RGB bitstream (v1 FLORA pixels, not v2)


// Example for NeoPixel Shield.  In this application we'd like to use it
// as a 5x8 tall matrix, with the USB port positioned at the top of the
// Arduino.  When held that way, the first pixel is at the top right, and
// lines are arranged in columns, progressive order.  The shield uses
// 800 KHz (v2) pixels that expect GRB color data.
Adafruit_NeoMatrix matrix = Adafruit_NeoMatrix(16, 16, PIN,
  NEO_MATRIX_TOP     + NEO_MATRIX_LEFT  +
  NEO_MATRIX_COLUMNS + NEO_MATRIX_ZIGZAG,
  NEO_GRB            + NEO_KHZ800);

const uint16_t colors[] = {
  matrix.Color(255, 0, 0), matrix.Color(0, 255, 0), matrix.Color(0, 0, 255) };

void setup() {
  matrix.begin();
  matrix.setTextWrap(false);
  matrix.setBrightness(40);
  matrix.setTextColor(colors[0]);
  matrix.setTextSize(1);
}

int x    = matrix.width();
int pass = 0;

void loop() {
  matrix.fillScreen(0);
  matrix.setCursor(x, 0);
  matrix.print(F("AZ-Delivery"));
  if(--x < -72) {
    x = matrix.width();
    if(++pass >= 3) pass = 0;
    matrix.setTextColor(colors[pass]);
  }
  matrix.show();
  delay(100);
}

Code bitcoin price:

// Adafruit_NeoMatrix example for single NeoPixel Shield.
// Scrolls 'Howdy' across the matrix in a portrait (vertical) orientation.

#include <Adafruit_GFX.h>
#include <Adafruit_NeoMatrix.h>
#include <Adafruit_NeoPixel.h>
#include "credentials.h"
#include <ArduinoJson.h>
#include <WiFi.h>
#include <HTTPClient.h>

// search for crypto apis
String serverName = "https://api.replacemewithyourfavoriteapi.com/price?ids=bitcoin%2Cdogecoin&vs_currencies=eur";
unsigned long previousMillis = 0;
float value_bitcoin = 0;
float value_dogecoin = 0;

#ifndef PSTR
#define PSTR // Make Arduino Due happy
#endif

#define PIN 16

// MATRIX DECLARATION:
// Parameter 1 = width of NeoPixel matrix
// Parameter 2 = height of matrix
// Parameter 3 = pin number (most are valid)
// Parameter 4 = matrix layout flags, add together as needed:
//   NEO_MATRIX_TOP, NEO_MATRIX_BOTTOM, NEO_MATRIX_LEFT, NEO_MATRIX_RIGHT:
//     Position of the FIRST LED in the matrix; pick two, e.g.
//     NEO_MATRIX_TOP + NEO_MATRIX_LEFT for the top-left corner.
//   NEO_MATRIX_ROWS, NEO_MATRIX_COLUMNS: LEDs are arranged in horizontal
//     rows or in vertical columns, respectively; pick one or the other.
//   NEO_MATRIX_PROGRESSIVE, NEO_MATRIX_ZIGZAG: all rows/columns proceed
//     in the same order, or alternate lines reverse direction; pick one.
//   See example below for these values in action.
// Parameter 5 = pixel type flags, add together as needed:
//   NEO_KHZ800  800 KHz bitstream (most NeoPixel products w/WS2812 LEDs)
//   NEO_KHZ400  400 KHz (classic 'v1' (not v2) FLORA pixels, WS2811 drivers)
//   NEO_GRB     Pixels are wired for GRB bitstream (most NeoPixel products)
//   NEO_GRBW    Pixels are wired for GRBW bitstream (RGB+W NeoPixel products)
//   NEO_RGB     Pixels are wired for RGB bitstream (v1 FLORA pixels, not v2)

// Example for NeoPixel Shield.  In this application we'd like to use it
// as a 5x8 tall matrix, with the USB port positioned at the top of the
// Arduino.  When held that way, the first pixel is at the top right, and
// lines are arranged in columns, progressive order.  The shield uses
// 800 KHz (v2) pixels that expect GRB color data.
Adafruit_NeoMatrix matrix = Adafruit_NeoMatrix(16, 16, PIN,
                                               NEO_MATRIX_TOP + NEO_MATRIX_LEFT +
                                                   NEO_MATRIX_COLUMNS + NEO_MATRIX_ZIGZAG,
                                               NEO_GRB + NEO_KHZ800);

const uint16_t colors[] = {
    matrix.Color(255, 0, 0), matrix.Color(0, 255, 0), matrix.Color(0, 0, 255), matrix.Color(255, 165, 0)};

void connectAP()
{
  Serial.println("Connecting to WiFi..");
  WiFi.begin(ssid, password);

  int cnt = 0;
  while (WiFi.status() != WL_CONNECTED)
  {
    delay(1000);
    Serial.print(".");
    cnt++;

    if (cnt > 20)
      ESP.restart();
  }
  Serial.println(WiFi.localIP());
}

int x = matrix.width();
int pass = 0;

void getCryptoData()
{
  if (WiFi.status() == WL_CONNECTED)
  {
    HTTPClient http;

    http.begin(serverName.c_str());
    int httpResponseCode = http.GET();
    if (httpResponseCode > 0)
    {
      Serial.print("HTTP Response code: ");
      Serial.println(httpResponseCode);
      String payload = http.getString();
      // Serial.println(payload);

      // JSON Output from https://arduinojson.org/v6/assistant

      StaticJsonDocument<96> doc;
      DeserializationError error = deserializeJson(doc, payload);

      if (error)
      {
        Serial.print("deserializeJson() failed: ");
        Serial.println(error.c_str());
        return;
      }

      value_bitcoin = doc["bitcoin"]["eur"];
      value_dogecoin = doc["dogecoin"]["eur"];

      Serial.println(value_bitcoin);
      Serial.println(value_dogecoin);
    }
    else
    {
      Serial.print("Error code: ");
      Serial.println(httpResponseCode);
    }
    http.end();
  }
  else
  {
    Serial.println("Reconnect to AP");
    connectAP();
  }
}

void showMatrix()
{
  // https://javl.github.io/image2cpp/
  // 'pixil-frame-0', 7x10px
  const unsigned char bitcoinlogo[] PROGMEM = {
      0x48, 0xfc, 0xfe, 0xc6, 0xfc, 0xfc, 0xc6, 0xfe, 0xfc, 0x48};

  matrix.fillScreen(0);
  matrix.setCursor(x, 0);
  matrix.print(value_bitcoin);
  if (--x < -72)
  {
    x = matrix.width();
    if (++pass >= 3)
      pass = 0;
    matrix.setTextColor(colors[pass]);
  }
  matrix.drawBitmap(4, 6, bitcoinlogo, 7, 10, colors[3]);
  matrix.show();
  delay(100);
}

void setup()
{
  Serial.begin(115200);
  connectAP();

  matrix.begin();
  matrix.setTextWrap(false);
  matrix.setBrightness(40);
  matrix.setTextColor(colors[0]);
  matrix.setTextSize(1);
}

void loop()
{

  unsigned long currentMillis = millis();
  if (currentMillis - previousMillis >= 15000)
  {
    previousMillis = currentMillis;

    getCryptoData();
  }

  showMatrix();
}

Credentials:

const char* ssid     = "az-delivery";
const char* password = "mysecretpassword";
